Application:
Mainly used for cutting the whole piece or roll of pearl cotton material into small pieces of material in different sizes.
Feature:
1. PLC programmable control system, servo motor feeding;
2. Cut the materials in multi-size with multi-knife, easy operation and high production efficiency;
3. The feed automatically trims the section between two edges;
4. Adjustment of numerical control of the pressing roller, and adjustable cutting speed;
5. The cutting size can be adjusted, and the CNC automatically adjusts the required size for cutting;
Parameters:
Model ML-1350 ML-1680 | Standard | High configuration |
| Max feed width | 1300 | 1600 |
| Cutting thickness | 3-80mm | 3-80mm |
| Left and right round knife slitting width | 25-1300mm | 45-1600mm |
| Front and rear cross cutter slitting width | 5mm-infinite | 5mm-infinit |
| Cutting speed | Adjustable 0-1m/s | Adjustable 0-1m/s |
| Dimensions(L,W and L mm) | Main unit:1900*1020*1410 Workbench:1920*1300*950 | Main unit:2130*980*1480 Workbench:2000*1230*1020 |
| Weight | 805KG | 1000KG |
| Total power | 4.65KW | 6.65KW |
| Voltage | Three-phase 380V+1N | Three-phase 380V+1N |
| Round knife adjustment | Manual | Manual |
| Cross cutter adjustment | Automatic | Automatic |
| Standard round knife | 5 PCS | 8 PCS |
| Standard cross cutter | 1 PCS | 1 PCS |
| Air pressure | 0.4-0.8 MPA | 0.4-0.8 MPA |
| Required wire | 3*2.52+1*1.52 | 3*42+1*1.52 |
Above parameters are subject to actual product, and all interpretation rights are owned by Maolong Machinery.
